Common-action Gardens #1
COMMON action GARDENS I is an urban garden structure that is exhibited and still in use in Karaalioglu Park as part of the 3rd Architecture Biennial Programme in Antalya. These structures are injected in formal park layouts as edible gardens whose aim is to support the “preserve, sustain, and share” concept and to bring people together while producing. These gardens organize sustainable models for living by integrating raised beds, planting holes, water bowls, compost holes, seedboxes, tool pots, niches for animals, and resting corners in one whole body. Digital design and production technologies help to establish a system and structure which adapts itself to the social, topographical, and material dynamics of the host park where each garden is located and to mediate each communal garden’s relation with the Earth through “production”. Geometric research to relate material systems composed of EVA and wood with environmental issues i.e. air, water, light, and anthropomorphic data for sitting positions is done via computational design and production technologies. The fluid form of the structure is produced via the contouring technique which is a sequence of CNC cut plates that are assembled by perpetual screws. Automatization of these plates’ tags enabled the assembly of the system in one night.
Video by Elif Soylu
Screen capture of an intermediate design phase, showing the Grasshopper tool developed to calculate and reduce the material used.
Final version to be produced:
Grasshopper definition used in form-finding and the calculation of material use
The final construction
IABA 2015 International Architecture Biennial
Antalya // October 2015, Exhibition at Karaalioğlu Park
Design and Prototyping: Fulya Akipek, Tuğrul Yazar, Aslı Aydın
Team of students: Alara Lüküs, Burak Güney, Elif Soylu, Tufan İşcan, Tunç Şenman
Consultants: Anonim İstanbul_Burcu Serdar Köknar, Hande Kalender, Dilek Yürük
